ProSource C363BV-PS Passage Knob, Metal, Stainless Steel, 2-3/4 in Backset, 1-1/4 to 1-13/16 in Thick Door
- Backset Size: 2-3/4 in
- Backset Type: Fixed
- Bolt Throw Size: 12.5 mm
- Cross Bore Diameter: 2-1/8 in
- Design: Ball
- Model #: C363BV-PS
- UPC #: 045734656918
- SKU: 7390263
Your shopping list will be used for pickup in-store
Product Details
For hall and closet doors, all interior doors where a simple latch is all that is required. Both knobs always free, no locking mechanism. All-metal components. Solid steel latch assembly. Seamless one piece knob for extra strength. Easy installation. Square spindle for right or left-handed installations. Fixed 2-3/4 in Backset Square Corner Latch, radius corner or drive-in applications, includes both T-Strike and ASA Strike.Key Features
- Commercial or heavy-duty residential security
- UL 3 hr fire rating
Item Specifications
| Backset Size | 2-3/4 in |
|---|---|
| Backset Type | Fixed |
| Bolt Throw Size | 12.5 mm |
| Cross Bore Diameter | 2-1/8 in |
| Design | Ball |
| Door Thickness | 1-1/4 to 1-13/16 in |
| Edge Bore Diameter | 1 in |
| Faceplate Size | 25.2 x 56.7 mm |
| Finish | Stainless Steel |
|---|---|
| Material | Metal |
| Mounting Type | Screw |
| Projection Size | 75 mm |
| Strike Size | 47 x 125.6 mm |
| Strike Type | Round Corner Square Corner |
| Suitable for | 1-1/4 to 1-13/16 in THK Doors |
| Throw Length | 12.5 mm |
MORE DETAILS:
- Application: For commercial buildings, hall, closet doors and all interior doors
